LAUNCH X431 PRO3 LINK SmartLink Passenger Diagnostic Scan Tool
The Launch X431 PRO3 LINK SmartLink is a professional-grade diagnostic scanner built for high performance across petrol, diesel and heavy-duty vehicles. Featuring Android 10, 10.1″ touch-screen, SmartLink C connector, full bi-directional control and ECU coding functions — it delivers factory-level diagnostics for repair shops and serious DIYers alike.
-
Android 10.0 OS + 10.1″ HD display (1280×800) — fast and intuitive interface
-
SmartLink C connector: supports local & remote diagnosis
-
Broad protocol support: CAN 2.0, CAN-FD, DoIP, J2534
-
OE-level all-system diagnostics for 110+ manufacturers
-
Full bi-directional active test, ECU online coding & programming
-
39 service functions: Oil reset, EPB, SAS, DPF regen, Throttle matching, Battery reset, ABS bleeding, Sunroof init, Headlight matching
-
Remote diagnostic capability via built-in WiFi/Bluetooth
-
Optional heavy-duty truck diagnosis (24V) via HD module add-on
Features
- Enables you to diagnose light, medium & heavy duty (optional) vehicles with Smartlink C.
- Full system vehicle coverage for U.S., Asian and European markets over 110 manufacturers, which is continually updated.
- Real-time voltage display is supported, which helps you monitor the voltage condition of the vehicle during the diagnosis.
- Intelligent diagnostic enables automatic VIN identity to automatically access systems quickly.
- Intelligent and local diagnostic, which include full diagnostic functions, such as read/clear DTC, live data streaming, bi-directional control, coding, etc.
- Guided functions for VW and AUDI. (Support a total of over 30,000 functions for VW and AUDI)
- Optional ADAS calibration function increases more revenue.
- Advanced coding and programming function.
- An extended solution to support TPMS service.
- The software is available to purchase separately on the MALL at any time.
- Built-in repair information and training videos help to track and fix issues fast.
ECU Coding
ECU Coding allows you to re-flash and reconfigure vehicle control modules after repairs or component replacements. This function restores adaptive data, resolves drivability issues, improves fuel efficiency, fixes power loss or fault codes, and ensures proper operation and durability of mechanical and electronic components.
Actuation Test (Bi-Directional Control)
Bi-directional control enables the scanner to send commands directly to vehicle systems and components to verify their operation without using the physical controls.
Common tests include:
• Radiator fan activation
• Throttle actuation
• Window and mirror operation
• Injector buzz test
• Interior/exterior light activation
• Horn test
• Door lock actuator test
…and more.
This helps quickly locate faulty parts and confirm successful repairs.
Service Functions
Expandable with Launch Add-On Modules
Enhance functionality with optional modules:
• TS Gun – TPMS learning & activation
• Borescope – Internal component inspection
• 4-Channel Oscilloscope – Advanced electrical diagnostics
• HD Module – 24V heavy-duty truck coverage
• Battery Tester – Battery health analysis
• ADAS Calibration Frame – Advanced driver-assistance system calibration
Specific![]()
ation
| Operation System | Android 10.0 |
| Display | 10.1″, 1280*800 |
| CPU | 2.0GHz, Quad-core |
| Memory | 4GB |
| Storage | 64GB |
| Battery | 47.88Wh (7.6V, 6300mAh) |
| Camera | Rear 8MP |
| VCI Connection | Bluetooth |
| Dimension | 274*190.5*40.5 mm |
| Interface | TYPE A*1 & TYPE C*1 |
