Autel PowerScan PS100 Power Circuit Probe Kit, Automotive Circuit Tester, 12V 24V Electrical System Diagnostic Tool
- Regular
- $175.00 incl. GST
- Sale
- $175.00 incl. GST
- Regular
- Unit Price
- per
Autel PowerScan PS100 Power Circuit Probe Kit, Automotive Circuit Tester, 12V 24V Electrical System Diagnostic Tool
The Autel PowerScan PS100 is a revolutionary circuit tester that allows you to check circuitry in one single step. With its AVOmeter, test light, built-in flashlight, short circuit indicator, relay/component tester, continuity tester, and bad ground indicator, it is the ultimate tool for every technician.
The Autel PS100 Car Circuit System Diagnostic Tool can quickly and accurately diagnose the electrical system, and solve problems such as circuit short circuits, open circuits, etc., making it an essential circuit scanner for every technician.
NOTE: Not applicable to all models. Please check whether it is suitable for your vehicle model before purchasing.
Autel PS100 Circuit Tester Kit - Do Everything For You
- DC voltage range: 0-65V +1 digit
- Resistance range: 0–200 KΩ
- Frequency response of tone passage: 0Hz to 10Khz
- Performs multi-service including power injection, measurement, ground testing
- Easy to read AVOmeter for voltage, current, and resistance
- Component activation with a flip of the power switch
- Identifies positive, negative, and open circuits instantly
- Test bad ground contacts instantly
- Checks continuity of switches, relays, and diodes
- Circuit breaker protected
- Extra 20ft (extendable) cable
- Built-in Flashlight for working in the dark
More Useful Features
- 4 diagnostic modes: DC voltage, AC voltage, resistance, and diode
- Voltage & Polarity Test with LED light and sound indicators
- Continuity Test for wires and components
- Signal Circuit Test for quick fault determination
- Find Short Circuit capability
- Find Bad Ground functionality
- Component activation in multiple configurations
- Test Trailer Lights and Connections
- Red/Green Polarity Indicator
Extra 20ft Extension Cable
- Additional 20FT extension cable for large vehicles like ships and trucks
- Allows testing of any vehicle circuit without moving the device
Power Supply Options
- Vehicle battery power supply
- Cigarette lighter power supply
Quick Self-Test
- Perform quick self-test before circuit/component testing
- Power switch activates positive/negative voltage with LED and tone indicators
Test Tool Specifications
| DC voltage range | 0-65V +1 digit |
| Resistance range | 0 – 200 KΩ |
| Frequency response of the tone | 0Hz to 10Khz |
| Circuit Breaker Rating current | 1 – 10 Amp |
| Display | TFT color display (160 x 128 dpi) |
| External Power | 12.0 or 24.0 V power is provided via the vehicle battery |
| Package including | 1* PowerScan PS100 1* 20ft. extension cable 1* Rugged blow molded case 1* Probe tip 1* Battery clips 1* Cigarette lighter adapter 1* User's Manual |
The Autel PowerScan PS100 Power Circuit Probe Kit is a reliable and powerful automotive circuit tester that can diagnose issues in 12V and 24V electrical systems. This diagnostic tool features a multi-functional LCD display that provides easy-to-understand readings and clear diagnostic information.
Autel has developed this diagnostic scanner with a wide range of advanced features, including a built-in voltmeter, continuity tester, and short circuit tester. It can also test polarity and can detect open circuits. The scanner's features enable users to quickly and accurately diagnose electrical system issues in vehicles.
The Autel PowerScan PS100 Power Circuit Probe Kit is user-friendly and simple to operate. You can easily switch between modes and select the appropriate test function with the touch of a button. This makes it easy for users to get accurate and reliable results quickly, which can save time and reduce diagnostic costs.
